Description
Key features:
-
Multiple MPPT inputs: Equipped with 4 MPPT inputs, allowing efficient management of solar arrays with different orientations.
-
High input current support: Supports a maximum input current of 16A per MPPT and 24A short-circuit current.
-
Low start-up voltage: 160V start-up voltage improves system flexibility.
-
High efficiency: Up to 97.5% efficiency ensures energy-efficient operation.
-
Emergency output and backup function: Provides power supply even during outages.
-
Battery support: Compatible with various lithium-ion batteries, with a maximum charge/discharge current of 50A/10kW.
-
Easy installation: Pre-wired battery, meter, and communication connectors enable quick and simple installation.
-
Flexible load management: Supports unbalanced and half-wave loads.
-
Enhanced battery protection: Built-in protection extends battery lifespan.
Inverter warranty | 10 years |
Max. efficiency | 98% |
Munkapontok száma | 4 MPPT |
Weight | 32.6 kg |
Phases | 3 phase hybrid |
Power | 10000 W |
Inverter type | Asymmetrical hybrid |
Dimensions | 600 x 500 x 230 mm |
Max. input voltage | 1000 V |
