The Solis-110K-5G-PRO is the most powerful member of the Solis three-phase grid-tied inverter family, developed for large-scale commercial and industrial solar systems. It is excellently suited for bifacial modules, system oversizing, and offers high efficiency and reliability.
Key Features:
-
8 independent MPPT inputs with 16 string connections.
-
40 A input current per MPPT, 32 A per string.
-
Compatible with bifacial (double-sided) modules.
-
Supports DC/AC oversizing >150%.
-
Maximum efficiency: 98.5%, EU efficiency: 98.0%.
-
Nighttime SVG function for reactive power control.
-
Intelligent I-V curve scanning and string monitoring.
-
Built-in AFCI 2.0 (arc fault protection – optional).
-
PID recovery support (optional).
-
IP66 protection, wide temperature and humidity tolerance.
-
Remote monitoring communication: RS485, Wi-Fi, GPRS, PLC (optional).
Technical Specifications:
-
Rated output power: 110 kW
-
Maximum AC power: 121 kVA / 121 kW
-
Rated grid voltage: 3/N/PE, 220/380 V or 230/400 V
-
Maximum DC input voltage: 1100 V
-
MPPT voltage range: 160–1000 V
-
Maximum short-circuit current: 8 × 50 A
-
THDi: < 3%
-
Power factor: > 0.99
-
Surge protection: DC Type II / AC Type II
-
Protection: Reverse polarity, overcurrent, overvoltage, temperature, insulation fault, grid monitoring
Size and Weight:
-
Dimensions (W × H × D):
-
Weight: 98 kg
The Solis-110K-5G-PRO is an ideal choice for large solar systems where outstanding efficiency, long lifespan, advanced monitoring, and easy integration are required.
|
