The Solis-100K-5G-PRO is a 100 kW three-phase grid-tied inverter designed for industrial and commercial-scale solar systems. The device belongs to Solis's new generation 5G-PRO series, offering outstanding efficiency, advanced protection, and intelligent monitoring features.
Key Features:
-
8 independent MPPT inputs with 16 string connections for systems with diverse orientations.
-
Maximum 40 A input current per MPPT, 32 A per string.
-
Compatible with bifacial (double-sided) modules.
-
Supports >150% DC/AC ratio, allowing system oversizing.
-
Maximum efficiency: 98.5%; EU efficiency: 98.0%.
-
Built-in arc fault protection (AFCI 2.0 – optional), PID recovery (optional).
-
Intelligent I-V curve scanning, string monitoring, nighttime SVG function.
-
IP66 protection, operating range from -30°C to +60°C.
-
Remote monitoring support: RS485, optionally Wi-Fi, GPRS, PLC.
Technical Specifications:
-
Rated output power: 100 kW
-
Maximum AC power: 110 kVA / 110 kW
-
Rated grid voltage: 3/N/PE, 220/380 V or 230/400 V
-
Maximum DC input voltage: 1100 V
-
MPPT voltage range: 160–1000 V
-
Maximum short-circuit current: 8 × 50 A
-
Power factor: > 0.99
-
THDi: < 3%
-
Protection rating: DC II / AC II surge protection, DC reverse polarity, overcurrent and overheating protection
-
Cooling: Intelligent fan cooling
-
Nighttime self-consumption: < 2 W
-
Maximum operating altitude: 4000 m
-
Relative humidity: 0–100%
Size and Weight:
-
Dimensions (W × H × D):
-
Weight: 98 kg
The Solis-100K-5G-PRO is the perfect choice for projects where high efficiency, reliability, smart monitoring capabilities, and easy installation are key — all in a durable and professional inverter.
|
