Attached documents
Description
| Property | Value |
|---|---|
| Rated Power (Pmax) | 440 W |
| Module Efficiency | 21.16 % |
| Power Tolerance | 0 to +5 W |
| Cell Type | Monocrystalline PERC |
| Number of Cells | 120 (6×20) |
| Dimensions (L × W × H) | 1775 mm × 1052 mm × 35 mm |
| Weight | 19.5 kg |
| Max System Voltage (Voc) | 1500 V DC |
| Temperature Coefficient (Pmax) | –0.36 %/°C |
| Frame | Anodized aluminum alloy |
| Glass | Tempered glass, 3.2 mm |
| Junction Box | IP68 |
| Connector | MC4 compatible |
| Cable Length | 900 mm |
| Product Warranty | 12 years |
| Performance Warranty | 25 years, max. 0.55% degradation per year |
| Certifications / Standards | IEC 61215, IEC 61730, UL 61730 |
| Fire Safety Class | Class C |
| Cell type | Monocrystal |
| Dimension | 2108 x 1048 x 35 mm |
| Power | 440 Wp |
| Number of modules per pallet | 27 db |
Manufacturer
With 60 years of presence in the solar panel market—longer than any other company in the industry—SHARP’s experience in the photovoltaic business is unparalleled. As a pioneer in the solar panel market, SHARP has promoted the use of photovoltaic technologies for decades and has delivered more than 50 million solar modules to its partners. SHARP PV modules are used worldwide across a wide range of applications and environments. From mountainous regions to deserts, from icy climates to extreme humidity and hot environments, SHARP panels have proven to be strong and reliable.
SHARP offers a wide range of high-performance PV modules for residential, industrial/commercial, and greenfield facilities. By applying solar energy in cutting-edge industries such as space exploration and eMobility, SHARP continues to demonstrate its unmatched innovation capabilities. The SHARP solar panel division is part of a company with a broad product portfolio and strong financial background, as confirmed by its presence on the Bloomberg Tier 1 list.
