Description
| Property | Value |
|---|---|
| Rated AC Power | 5 000 W |
| Maximum Apparent Power | 5 500 VA |
| European Weighted Efficiency | 97.8 % |
| Max. Efficiency | 98.4 % |
| Number of MPPT Trackers | 2 |
| Recommended Max. PV Power | 7 500 Wp |
| Max. DC Input Voltage | 600 V |
| Start-up DC Voltage | 100 V |
| MPPT Operating Voltage Range | 90–560 V |
| Nominal DC Input Voltage | 360 V |
| Max. DC Current per MPPT | 12.5 A |
| Max. DC Short-Circuit Current per MPPT | 18 A |
| AC Grid Connection | Single-phase (220/230/240 V, 50/60 Hz) |
| Max. Output Current | 25 A |
| Power Factor Adjustable Range | 0.8 inductive to 0.8 capacitive |
| Total Harmonic Distortion (THD) | ≤ 3 % |
| Backup Function Support | Yes, via Backup Box B0 |
| Safety Features | Anti-islanding, DC/AC surge protection, short-circuit, residual current, arc fault protection |
| Battery Compatibility | Huawei Smart ESS, LG RESU 7H/10H |
| Communication Interfaces | RS485, built-in Wi-Fi, optional Ethernet or Smart Dongle 4G |
| Nighttime Power Consumption | < 2.5 W |
| Operating Temperature Range | –25 °C to +60 °C (derating above 45 °C) |
| Relative Humidity | 0 % – 100 % RH |
| Maximum Operating Altitude | 0 – 4 000 m (derating above 2 000 m) |
| Cooling Method | Natural convection (fanless) |
| Ingress Protection Rating | IP65 |
| Dimensions (W × H × D) | 365 × 365 × 156 mm |
| Weight (with mounting bracket) | ~ 12 kg |
| Warranty | 10 years (extendable with registration) |
| Product family | L1 - single phase |
| Max. efficiency | 98.4% |
| Weight | 12 kg |
| Phases | 1 phase |
| Power | 5000 W |
| Dimensions | 365 x 365 x 156 mm |
| Max. input voltage | 600 V |
Manufacturer
Huawei, as a global leader in ICT and network energy solutions, serves over 3 billion people worldwide.
With nearly 194,000 employees, the company operates in more than 170 countries and regions. Over the past decade, Huawei has invested more than USD 70 billion in development and continues to pursue customer-centric innovation, committed to enhancing the customer experience and delivering top-quality products and services.
Huawei offers leading intelligent PV solutions, backed by over 30 years of expertise in digital information technology. As the world’s largest inverter supplier from 2015 to 2021 — for six consecutive years — Huawei is committed to building efficient, smart, safe, reliable, and grid-supporting photovoltaic systems.
