Description
| Specification | Value |
|---|---|
| Rated AC Power | 6 000 W |
| Max. Apparent Power | approx. 6 600 VA |
| European Weighted Efficiency | 97.8 % |
| Maximum Efficiency | 98.4 % |
| Recommended Max. PV Power | 9 000 Wp |
| Max. Input Voltage (DC) | 600 V |
| MPPT Operating Voltage Range | 90 V – 560 V |
| Start-up Voltage (DC) | 100 V |
| Max. DC Input Current per MPPT | 12.5 A |
| Max. DC Short-Circuit Current | 18 A |
| Number of MPPT Trackers | 2 |
| Backup Function Support | Yes (BackupBox compatible) |
| Communication Interfaces | RS485, built-in Wi‑Fi; optional Ethernet or 4G dongle |
| Nighttime Power Consumption | < 2.5 W |
| Cooling | Passive, fanless |
| Protection Rating | IP65 |
| Operating Temperature Range | –25 °C to +60 °C |
| Relative Humidity | 0 % – 100 % RH |
| Max. Operating Altitude | 4 000 m (derating above 2 000 m) |
| Dimensions (W × D × H) | approx. 365 × 365 × 156 mm |
| Weight | approx. 12 kg |
| Warranty | 10 years |
| Product family | L1 - single phase |
| Max. efficiency | 98.4% |
| Weight | 12 kg |
| Phases | 1 phase |
| Power | 6000 W |
